Features:
1.Reflected from different angle, luminance can reach 1,300,000LUX.
2.BConcentrated light, high uniformity.
3.Compact structure.
Applications:
1.Scratch, bubble, stain, fingerprint in the mobile screen surface.
Distribution of relative luminance Distribution of relative irradiance
Model:LTS-3LINM500-W
Illumination property diagram
Model:LTS-3LINM500-W
Imaging instance:scratch inspection
Applications
Multi-area line scan light and tunnel line scan light effect contrast
Scratch inspected from multiple angle, multiple direction light path have strong direction, obvious contrast between scratch and background.
Tunnel line scan light have good uniformity, so that the defect homogenization, to make the contrast between scratch and background is not obvious.
Coding rule
Model |
Color |
Dimension |
Voltage |
Power |
LTS-3LINM100-R/BGW | / | L116xW313xH82(mm) | 24V | 96W |
LTS-3LINM200-R/BGW | / | L216xW313xH82(mm) | 24V | 192W |
LTS-3LINM300-R/BGW | / | L316xW313xH82(mm) | 24V | 288W |
LTS-3LINM400-R/BGW | / | L416xW313xH82(mm) | 24V | 384W |
LTS-3LINM500-R/BGW | / | L516xW313xH82(mm) | 48V | 576W |
LTS-3LINM600-R/BGW | / | L616xW313xH82(mm) | 48V | 768W |
LTS-3LINM700-R/BGW | / | L716xW313xH82(mm) | 48V | 864W |
LTS-3LINM800-R/BGW | / | L816xW313xH82(mm) | 48V | 864W |
* UV & IR light can be customized as required. |
