Projection structure light (2STL)

Features:

1.The structure upgrade is simple, the weight is lighter, and the cost performance is higher.
2.The sharpness and precision of the projected pattern have been enhanced.
3.LED projection structured light suitable for 3D imaging.
4.Parallel light usage can also be changed.

Applications:

1.Three-dimensional reconstruction and analyze.
2.Mechanical calibration.
3.Visualization and mapping.
4.Electronic components dimension measurement.

Effect comparison diagram                                                                                                  Applications



Grid Chip Customization Instructions


Lens and light spot dimensions                                                                                                     Line pattern: width is 0.05mm, length is 7.5mm.
